Accessories supplied with the unit
Fluke TL75 test leads
Holster
User manual
9 V battery (installed)
Detailed description
- The Fluke 113 digital multimeter is a quick and easy way to perform basic device setup and reconnection tests. This digital multimeter is easy to use and has features to quickly identify almost any electrical problem. The Fluke 113 digital multimeter offers significant improvements over other digital multimeters on the market, including the Fluke 7-600 model. Using Fluke VCHEK™ LoZ, a low input impedance measurement function, the user can measure voltage and continuity simultaneously. LoZ low input impedance measurements also block “ghost voltages” generated by nearby conductors. * Be aware that low input impedance LoZ measurements place a small load on a circuit protected by an FRCD, which can cause the RCD to trip. The min/max function can be used to record signal fluctuations. The Fluke 113 digital multimeter can be used to perform diode tests. It also offers both automatic and manual range selection. With features such as compliance with the latest safety standards and a much larger and easier to read backlit display, this digital multimeter is a must in any toolbox.
Features
- True RMS measurement method for precise AC voltage measurements with non-linear loads
- Large display with backlight ensures good readability everywhere
- Min/max function for recording signal fluctuations
- Diode test for testing universal germanium, silicon and power diodes
- Integrated holster with probe tip holders for easy storage
- Automatic and manual range selection for improved user functionality
- Compliance with CAT III 600 V and IV 300 V safety standards for a higher level of safety
- Optional TPAK magnetic holder for hands-free operation
Physically
– Color/Finish yellowblack
