Rigport L1S4 powerCON blue » 04 x SchukoD, black

Description

Downloads

Manufacturers Page

Features

• Pre-assembled system based on RigPort
• Lower loop resistance due to minimal number of connectors
• Significantly reduced setup times
• Not suitable for mounting with RigPort clamps
• 4 holes for permanent installation
• Not only suitable for event technology, but also as a clean, unobtrusive, and expandable power supply for offices or conference rooms

Physically

– Housing polyamide
– IP protection IP20
– Color/Finish black
– Dimensions | L: 345mm | W: 82mm | H: 71mm
– Weight 0,78 kg

Electrically

– electrical protection class Isolated
– Operating voltage 240VAC 50/60Hz
– Max. Rated Current 16A

Power connector input
01 x powerCON blue

Power connector output
04 x Schuko D with hinged lid
01 x powerCON grey (loop)
