Product Overview
Manufacturers Page
Accessories supplied with the unit
Integrated rubber protective frame for increased grip and impact resistance, rear stand and measuring lead holderProtective bag
High-quality silicone measuring leads with gold-plated 2 mm and screw-on 4 mm measuring tip
Wire temperature sensor
Batteries (3 x 1.5 V Micro AAA/ IEC LR03)
- Precise due to true RMS measurement method (TRUE RMS)
- Highest measurement category CAT IV 600 V for maximum protection against overvoltages
- AutoV function for automatic AC/DC voltage detection and low input impedance LoZ to suppress reactive voltages
- Continuity test via buzzer and red LED for noisy environments
- Voltage sensor signals phase voltages and cable breaks in lines without contact (red LED/buzzer)
- Robust housing design thanks to integrated rubber protective frame with magnetic hanger
- Compact protective bag and other accessories included in the scope of delivery
Features
- Display range: 6,000
Basic accuracy: 0.5 %
Measuring method: TRUE RMS
Measurement category: CAT IV 600 V
Voltage AC: 0.1 mV – 1000 V
Voltage DC: 0.1 mV – 1000 V
AC current: mA – 10 A
DC current: 1 mA – 10 A
Resistance: 0.1 Ω – 40 MΩ
Continuity | Diode: Yes | Yes
Frequency: 0.01 Hz – 100 kHz
Capacity: 1 nF – 10 mF
Voltage sensor: Yes
Memory function: HOLD, PEAK, REL
Physically
– Color/Finish redblack
