Accessories supplied with the unit
2 x 1.5 V micro batteries (LR03 / AAA)
- – Voltage from 12 V – 690 V AC / DC (LED)
– Display levels: 12, 24, 50, 120, 230, 400, 690 V AC / DC are fully functional with empty or removed batteries
– Acoustic and visual continuity test up to 100 kΩ (buzzer/ yellow Ω-LED)
– Single-pole phase conductor test (phase) (red LED)
– Polarity test (+/- LEDs)
– Non-contact phase tester / cable break detector (yellow LED)
– Test handle lock for one-handed operation on sockets and for safe storage
– Protection class IP 54 (dust / splash-proof)
– Impact-resistant and robust housing design
– built and tested in accordance with DIN EN 61243-3, VDE 0682-401:2015
– overvoltage category CAT III 600 V, CAT II 690 V
Physically
– IP protection IP54
– Color/Finish redblack
