Detailed description
- The expressive, crisp colored or pure white beam can be freely adjusted in color temperature from 2,500 to 10,000 Kelvin via a separate CTC channel. Optical quality is a priority with the impression FR1, ensuring that the beam remains clean, homogeneous, and clearly defined across the entire zoom range. Thanks to this consistent focus and GLP’s renowned attention to detail, the impression FR1 can be used in a wide range of applications that demand uncompromising quality.
A super-fast 1:10 zoom with a beam angle of 3.7 to 35 degrees allows full control over short and long distances. Thanks to the 60 W LED and the very narrow beam, the impression FR1 can also be used for lighting tasks over long distances. Added to this are dimming and position accuracy, both with 16 bits, in a range of 629 degrees pan and 210 degrees tilt. Furthermore, the impression FR1 offers continuous pan rotation in both directions and a full speed range from slow and smooth to extremely fast. A variety of dimming curves, different PWM frequencies, and many other settings are available via the intuitive device menu, with the most important functions also accessible via DMX.
Of course, the impression FR1 features GLP’s well-known baseless design. Thanks to Power In/Out, multiple devices can be easily wired together. The integrated threaded inserts and safety points provide the necessary flexibility for secure suspended mounting.
The impression FR1 offers an outstanding combination of quality, performance, compact design, and features—with that extra kick when it matters most.
Light source
– 60W LED Engine (x1)
– 790lm | 50’000 h
– Red, green, blue, white | CRI: 80+
Brightness control
– 100%, electronic, 16 bit | Strobe, Pulse, Sparkle, etc.
Positioning
– PAN: 629° / TILT 210°
Colors
– Tunable White 2500K-10000K
– Tungsten simulation 8x linked to fixed CCT | 8x relative to Colormix
– virtual, 64 LEE referenced colors, rainbow
Optical system
– Frontlens 100mm
– Motorized Zoom Optic 3.7° to 35°
Physically
– Housing Impact-resistant, flame-retardant thermoplastic, aluminum, sheet steel. Baseless Design
– Mounting method Eyelets for safety cables, 1x M10 threads
– IP protection IP20
– Color/Finish white
– Dimensions | W: 190mm | H: 264mm | D: 140mm
– Weight 4 kg
Thermally
– Ambient temperature 5°C – 45°C
– Combination of convection and forced cooling
Electrically
– electrical protection class Protection Earth
– Operating voltage 180 – 250VAC, 50-60Hz
– Power consumption 350W
Power connector input
Neutrik powerCON blue
Power connector output
Neutrik powerCON grey
Control
– Protocol DMX USITT DMX512-A, RDM ANSI/ESTA E1.20
– Protocol Output DMX USITT DMX512-A, RDM ANSI/ESTA E1.20
– 6 DMX Modes with 22, 33, 36, 51, 32, 39 DMX-Channels
Inout
01 XLR5 Chassis Male
Output
01 XLR5 Chassis Female
