Detailed description
- The new square lens design ensures maximum lumen efficiency and creates an unprecedented light curtain in the narrowest zoom range of just 4.5°, as well as uniform and homogeneous color distribution across the entire range up to the widest wash of 60°.
As part of the new GLP X5 family, the X5 IP Bar offers a comprehensive feature set, including selectable calibrated color temperatures, a tungsten simulation channel, magenta/green correction, a virtual color wheel, and variable CTC, as well as layer effects with numerous dynamic pattern macros.
The impression X5 IP Bar 1000 offers fast tilt movement combined with seamless, patented pixel pitch across all devices and comes standard with wired and wireless control.
The IP65 housing of the impression X5 IP Bar 1000 withstands all adverse environments, from confetti, fog, and pyro to dust and, of course, rain.
Features
- super fast zoom for punchy 4.4° narrow curtain to 63° homogen wide wash
- up to 7,500 lm Output and high Color Rendering with CRI 87
- innovative GLP iQ.Mesh and iQ.Gamut technology
Light source
– 40W Multichip LED square (x18)
– max. 7’500lm | 50’000 h
– Red, green, blue, Lime | CRI: 8’000K: 87, 6’500K: 86+, 3’200K: 84+
Brightness control
– 0 – 100%, 16 bit, Strobe, Pulse, Sparkel etc.
Positioning
– Tilt: 205°
Colors
– RGB, RAW, x;y
– Tunable White 2500K-10000K
– Color wheel: virtual, 64 LEE referenced colors, rainbow
Optical system
– 18 square lenses 48 x 48mm
– Motorized zoom optics 4.4° to 63°
Physically
– Housing Impact-resistant flame-retardant thermoplastic, aluminum, sheet steel.
– Mounting method Tilt-lock system, alignment system, thread for external accessories, slide-in filter system
– Fastening 2 eyelets for safety cables, 4 pairs of 1/4-turn locks for 2 installation brackets
– IP protection IP65
– Color/Finish black
– Dimensions | W: 1000mm | H: 316mm | D: 143.5mm
– Weight 27 kg
Thermally
– Ambient temperature -10°C – 45°C
– Combination of convection and forced cooling
Electrically
– electrical protection class Protection Earth
– Operating voltage 100 – 240VAC 50/60Hz
– Power consumption 700W
Power connector input
Neutrik powerCON True 1 Chassis IP65
Power connector output
Neutrik powerCON True 1 Chassis IP65
Control
– Protocol DMX USITT DMX512-A, RDM ANSI/ESTA E1.20
– Protocol Output DMX USITT DMX512-A, RDM ANSI/ESTA E1.20
– 6 DMX Modes with M1: 20, M2: 33, M3: 48, M4: 84, M5: 63, M6: 81 DMX-Channels
Inout
01 Neutrik XLR5 Chassis Male IP65
Output
01 Neutrik XLR5 Chassis Female IP65
Network
– Protocol Art-Net, sACN, GLP iQ.Mesh
– Protocol Output Art-Net, sACN, GLP iQ.Mesh
Input
Neutrik etherCON IP65
Output
Neutrik etherCON IP65 (A & B Failsafe
