Detailed description
- This IP65-certified LED wash light impresses with exceptional light output and outstanding color mixing, which designers worldwide appreciate in the X5 Wash.
The impression X5 IP features powerful 19 x 40-watt RGBL LEDs that deliver a light output of up to 11,400 lumens. The GLP iQ.Gamut color algorithm ensures precise color mixing without loss of brightness, natural skin tones, and flexible color temperatures between 2,500 and 10,000 K. With a CRI of up to 86.7 and a TLCI of 88.5, it meets the highest standards for color rendering.
The optical system includes a motorized 17:1 zoom, ranging from a narrow 3.6° beam to a wide 63° wash. In addition to homogeneous illumination, the X5 IP offers pixel mapping functions and dynamic effects that enable creative lighting designs.
Thanks to its IP65 certification, the impression X5 IP is perfect for outdoor events, festivals, and tours. Its sealed housing protects against dust, dirt, moisture, and pyrotechnic and confetti particles, even indoors, ensuring flexible use and minimal maintenance.
With a lightweight and compact design, the spotlight weighs less than 21 kilograms, allowing for quick and easy installation. Various control options such as DMX, RDM, ArtNet sACN, and Lumenradio CRMX, as well as the integration of NFC and iQ.Mesh, ensure uncomplicated configuration. Despite its performance, the device is energy-efficient and economical with a power consumption of 700 watts at 230 volts.
With the impression X5 IP, GLP brings the innovation, robustness, and creative freedom of the X5 Wash to the outdoor sector.
Light source
– 40W Multichip LED (x19)
– < 11’400lm | 50’000 h
– Red, green, blue, Lime
– Low: 550 Hz | Optimal: dynamic PWM Algorithm | High 1: 4.600 Hz | High 2: 13.000 Hz
Brightness control
– 100%, electronic, 16 bit | Strobe, Pulse, Sparkle, etc.
Positioning
– PAN: 540° / TILT 230°
Colors
– Tunable White 2500K-10000K
– Tungsten simulation 8x linked to fixed CCT | 8x relative to Colormix
– virtual, 64 LEE referenced colors, rainbow
Optical system
– Frontlens 278mm
– Motorized Zoom Optic 3.6° to 36°
Physically
– Housing Impact-resistant, flame-retardant thermoplastic, aluminum, sheet steel. Tilt-Lock system
– Mounting method 2 pairs of 1/4 twist locks | Eyelets for safety cables | 2x M10 threads
– IP protection IP65
– Color/Finish black
– Dimensions | W: 377mm | H: 530mm | D: 324mm
– Weight 21 kg
Thermally
– Ambient temperature -10°C – 45°C
– Combination of convection and forced cooling
Electrically
– electrical protection class Protection Earth
– Operating voltage 180 – 250VAC, 50-60Hz
– Power consumption 700W
Power connector input
Neutrik powerCON True 1 TOP
Power connector output
Neutrik powerCON True 1 TOP
Control
– Protocol DMX USITT DMX512-A, RDM ANSI/ESTA E1.20
– Protocol Output DMX USITT DMX512-A, RDM ANSI/ESTA E1.20
– 6 DMX Modes with 24, 35, 41, 89, 70, 89 DMX-Channels
Inout
01 XLR5 Chassis Male IP65
Output
01 XLR5 Chassis Female IP65
Wireless receiver (RX)
– Standard LumenRadio CRMX DMX/RDM |
Network
– Protocol Art-Net, sACN, GLP iQ.Mesh
– Protocol Output Art-Net, sACN, GLP iQ.Mesh
Input
Neutrik etherCON IP65
Output
Neutrik etherCON IP65
