Detailed description
- Equipped with highly efficient RGBAL LEDs and the innovative GLP iQ.Gamut color algorithm, the MATRIX Eye delivers powerful color rendering and high-quality white light with excellent color rendering quality. The device reproduces the behavior of traditional DWE blinder – including an authentic, warm dimming curve – and combines this look with the advantages of modern LED technology.
The MATRIX Eye is designed for maximum performance and high cost-effectiveness. Its sophisticated, cost-efficient design ensures a low purchase price, fast amortization, and attractive rental conditions – perfect for companies that value reliability, versatility, and cost-consciousness.
Take your lighting design to the next level – with the GLP MATRIX Eye, where innovation meets tradition.
Features
- 100° Field Angle with up to 19’650lm
- Realistic tungsten simulation with CRI 90+ @ 6’500K
- +/-20° individual Head-Pan-Angle
- IP65 protected for indoor and outdoor
- compact and low weight framing construction for multiple fixture cluster
Light source
– 500W LED Engine (x2)
– max. 13’165lm | 50’000 h
– Red, green, blue, amber, lime
Brightness control
– 16-bit electronic dimming with 3 different dimming curves: linear, S-curve, square
– Tungsten simulation 8x linked to fixed CCT, 8x relative to Colormix
Colors
– RGB, RGBAL
– Tunable White 2500K-10000K
– White points 8,000K, 6,500K, 5,600K, 4,200K, 3,200K, Off
Optical system
– Beam Angle 60°
Physically
– Housing Impact-resistant, flame-retardant housing made of thermoplastic, aluminum, and sheet steel.
– Mounting method 3 pairs of 1/4 twist locks (top and sides of frame, arm), 2x eyelets for safety cable (rear)
– Fastening Alignment & Linking System | +/- 20° tilt angle for each head
– IP protection IP65
– Color/Finish black
– Dimensions | W: 200mm | H: 200mm | D: 246mm
– Weight 11,1 kg
Thermally
– Ambient temperature -10°C – 45°C
– active fan cooling
Electrically
– electrical protection class Protection Earth
– Operating voltage 100 – 240VAC 50/60Hz
– Power consumption 1’200W
Control
– Protocol DMX USITT DMX512-A, RDM ANSI/ESTA E1.20
– 4 DMX Modes with 2, 19, 38, 6 DMX-Channels
Inout
01 Neutrik XLR5 Chassis Male
Output
01 Neutrik XLR5 Chassis female
