Description
Detailed description
- The MINDER S2 pulley is designed for professionals working at height and for setting up a rescue system at the site of an incident. The special side plates are designed for use with a self-locking Prusik knot in systems with a backstop. The lightweight and compact pulley offers good efficiency for handling medium-heavy loads.
Use in systems with non-return valve:
- Movable side panels with a design based on self-locking Prusik knots.
Designed for handling medium-heavy loads
- – High efficiency thanks to rollers with encapsulated ball bearings.
- The connection eyelets enable most carabiners that comply with European standards to be reversed.
– Enables the creation of complex pulley systems thanks to the two rollers positioned one behind the other and the additional attachment eyelet.
– Compact and lightweight.
– Protected rope passage thanks to the specially designed side plates.
Features
- – Ball bearings: yes
– Efficiency: 91%
– Maximum working load: 6 kN
– Breaking load: 23 kN
– Breaking load of the additional attachment eyelet: 12 kN
Physically
– Rope Diameter 6-11mm
– by Standard CE EN 12278, UIAA, NFPA Technical Use, XF 494 Light
– Housing Aluminum, stainless steel
– Color/Finish yellowblack
– Dimensions | Ø: 25mm
– Weight 0,071 kg
