Features
- Digital display voltmeter ammeter, blue
- Voltage measuring range: 60 V to 500 V, measuring accuracy ±1
- Current measurement: 0 to 100 A, measuring accuracy ±1
- CEE Inline
- small maintenance-free on-stage power distribution units
- Completely black for the most inconspicuous installation possible
- Can be mounted in the traverse with RPL-Clamp50
- 1x M10, 2x M4
- suitable for outdoor use
Physically
– Housing Sheet steel
– IP protection IP54
– Color/Finish black
– Dimensions | L: 321mm | W: 90mm | H: 100mm
– Weight 1,6 kg
Electrically
– electrical protection class Protection Earth
– Operating voltage 400V/230V AC 50Hz
– Max. Rated Current 3 x 32A
Power connector input
01 x Chassis plug PCE CEE32-5 black
Power connector output
01 x PCE CEE32-5 black
