Detailed description
- Supply voltage: 100-277 V, 50/60 Hz
- Power consumption: 240 W
- Mains power connector: Neutrik powerCON TRUE1 in/out
- DMX and RDM data: lockable 3-pin & 5-pin XLR in/out
- Integrated network switch 10/100 Mbps: 1x in/1x out
- Network interface: RJ45 in/out
- Mains power and data: lockable 4-pin XLR out (from PATT driver to PATT 2017)
Physically
– IP protection IP20
– Color/Finish black
– Dimensions | W: 82mm | H: 358mm | D: 162mm
– Weight 3 kg
Electrically
– electrical protection class Protection Earth
– Operating voltage 100-277 V, 50/60 Hz
