Accessories supplied with the unit
incl. anti-glare protection, Omega temples
Detailed description
- Due to its compactness, narrow beam angle and IP65 certification, it is particularly suitable for trade fair applications, as well as indoor and outdoor building and architectural lighting, but of course also for theater and show lighting. The NANOBAR is at home wherever small dimensions combined with a strong light output and different color temperatures are required.
Light source
– 5W LED Engine 2-in-1 (x36)
– warm white – cold white
Colors
– Tunable White 2400K-6900K
Optical system
– Beam Angle 10 x 60°
Physically
– Aluminum housing with holes for M3 screws and omega bracket
– IP protection IP66
– Color/Finish black
– Dimensions | L: 395mm | W: 53mm | H: 85mm
– Weight 1,886 kg
Electrically
– electrical protection class Protection Earth
– Operating voltage 100 – 240VAC 50/60Hz
– Power consumption 55W
Power connector input
Lockable chassis plug 16A True 1
Power connector output
Lockable chassis socket 16A True 1
Control
– Protocol DMX, RDM
Inout
01 XLR3 Chassis Male IP65
Output
01 XLR3 Chassis Female IP65
