Proplex FOH™ Friend DAC, 9.5″, 1U portable, blue

Description

Technical data at a glance

with USB-C connection for digital audio & timecode signals. Will also function as a main/backup timecode or audio switch.
In: USB-C | 5VDC for Headphone Amplifier
Rack-mount enclosure portable 9.5 inch | 1U
Dimensions (mm) | T: 129 | B: 183 | H: 43,7 | 0,54kg

:: Useful for: unique Tool for Every Show Programmer – Media, Lighting and Audio

:: Included Accessories:
– Pouch

Downloads

User Manual
Rack Mount Kit Manual
Specification
Manufacturers Page
Technical Drawing (.pdf)

Detailed description

• Work with your local timecode and audio track files until the stage calls!
• Instantly switch between two timecode and audio sources
• All the outputs and controls you need for timecode and audio tracks
• Make use of every minute of your valuable programming time
• A durable, compact unit that goes with you anywhere. Single and Dual RackMount Kits available.

Features

• Timecode distributor
• three passive TC outputs, works even with USB disconnected
• Passive audio output with volume control
• USB powered headphone amp
• USB sound card
• playback audio/timecode files during programming and record live

audio with timecode during rehearsals

• Split headphone mode
• for sync verification in video playback
• Level meter LEDs to indicate signal presence or overload

Physically

– Rack-mount enclosure portable 9.5 inch | 1U
– Color/Finish blue
– Dimensions | W: 183mm | H: 43,7mm | D: 129mm
– Weight 0,54 kg

Thermally

– Ambient temperature -20°C – 40°C

Electrically

– electrical protection class Safety Extra Low Voltage, SELV
– Operating voltage 5VDC for Headphone Amplifier

Power connector input
USB-C

Input
USB-C
01 XLR3 Chasses Female Combo Jack 6.3mm TRS Timecode
01 XLR3 Chasses Female Combo Jack 6.3mm TRS Audi

Input Protocol
Digital Audio, Analogue Audio, Timecode

Output
03 XLR3 Chasses Male Combo Jack 6.3mm TRS Timecode
01 XLR3 Chasses Male Combo Jack 6.3mm TRS Audi
01 Jack 6.3mm TRS Audio
01 Jack 3.5mm TRS Headphone
01 Jack 6.3mm TRS Headphone

Output Protocol
Digital Audio, Analogue Audio, Timecode
