Description
Downloads
Technical Information
Manufacturers Page
Features
- Provides 2 independent 4-way splits
- Use loop for 1-in-8-out
- Optical and galvanic isolation
- Does not support RDM
Physically
– Housing 19 inch rack case 1U
– IP protection IP20
– Color/Finish black
– Dimensions | L: 483mm | W: 183mm | H: 45mm
– Weight 4 kg
Thermally
– Convection cooling
Electrically
– Operating voltage 85 – 265VAC 50/60Hz
Power connector input
Inlet C14 IEC-60320
Control
– Protocol DMX
Inout
01 XLR5 Chassis Male
Output
01 XLR5 Chassis Female Loop Out
02 x 4 XLR5 Chassis Female, optical isolated
Amount of Universes 1 (512 DMX-Channels)
