Physically
– IP protection IP20
– Color/Finish black
– Dimensions | W: 326mm | H: 132,5mm | D: 205.5mm
– Weight 4,1 kg
Thermally
– Ambient temperature 5°C – 45°C
Electrically
– electrical protection class Protection Earth
– Operating voltage 90 – 240VAC 50/60Hz
– Power consumption 350W
Power connector input
powerCON 20A Chassis (blue)
Power connector output
01 x powerCON 20A Chassis out (grey)
12 x XLR4 Chassis Female (24V&Data) per X4 ATOM
Control
Inout
01 XLR5 Chassis Male
Output
01 XLR5 Chassis female
