Physically
– Housing Impact-resistant, flame-retardant thermoplastic, aluminum, sheet steel, 2 handles, 2 mounting plates
– Mounting method 1 pair of 1/4 twist locks, 2 eyelets for safety cables, 2x M6 threads, M10 thread, mounting baseplate (included)
– IP protection IP65
– Color/Finish black
– Dimensions | W: 314mm | H: 153mm | D: 230mm
– Weight 5,2 kg
Thermally
– Ambient temperature -10°C – 45°C
Electrically
– electrical protection class Protection Earth
– Operating voltage 90 – 240VAC 50/60Hz
– Power consumption 350W
Power connector input
powerCON True 1
Power connector output
01 x powerCON True 1
12 x XLR4 Chassis Female (24V&Data) per X4 ATOM
Control
Inout
01 XLR5 Chassis Male
Output
01 XLR5 Chassis female
