Detailed description
- The D4 is used to power and control the XOOP 290-1 & 200-2 LED trusses. It has 4 outputs, whereby each output can supply up to 96W. This corresponds to 4-5m of LED truss. Each output is equipped with lockable RJ45 sockets. RJ45 connections are also available for DMX control, as are 5-pin XLR sockets. The driver is IP65 certified and is perfect for direct installation on the truss. For this purpose, the device also has a LumenRadio interface for wireless control of the driver.
Features
- Driver for XOOP 200-2 & 290-1 LED
- 04 x RJ45 output
- 96W per output
- DMX modes: 1, 2, 3, 4, 7, 64 &112 channel
- DMX: 5-pin XLR In/Out & RJ45 In/Out
Physically
– Aluminum housing with M10 thread for clamp, additional mounting holes
– IP protection IP65
– Color/Finish black
– Dimensions | W: 337mm | H: 105mm | D: 241mm
– Weight 3,9 kg
Thermally
– Ambient temperature -5°C – 65°C
– Forced cooling with silent fan
Electrically
– electrical protection class Protection Earth
– Operating voltage 90-264 V AC, 50/60 Hz
– Power consumption 500W
– Output Voltage 04 x 24V. To use the D4 driver in combination with the Xoop LED trusses, CAT6 AWG 23 or thicker with RJ45 plugs should be selected.
– Output Current 04 x 4A
– Output Wattage 04 x 96W
Power connector input
Seetronic SAC3 IP65
Power connector output
04 x RJ45 IP65
Control
– Protocol DMX512, Stand Alone
– Protocol Output DMX512, Stand Alone
– 7 DMX-Modes with 1, 2, 3, 4, 7, 64 &112 DMX-Channels
Inout
01 XLR5 Chassis Male IP65
01 RJ45 IP65
Output
01 XLR5 Chassis Female IP65
01 RJ45 IP65
Amount of Universes 1 ( DMX-Channels)
Wireless receiver (RX)
– Standard LumenRadio CRMX™
