Detailed description
- D3 Wing expands your D3 setup with additional faders and buttons, giving you more physical control for live playback, cue stacking, and quick programming. It is perfectly matched to the D3 series and features the same angles, layout, and red LED display.
User Interface (Hardware)
- 20x 60mm playback faders
- 40x C&K flash buttons with custom cap
- 03x backlit Cherry MX Low Profile playback paging keys
- 30x backlit Cherry MX Low Profile macro/executor keys
Physically
– Housing Aluminum console housing
– IP protection IP20
– Color/Finish black
– Dimensions | W: 398mm | H: 78mm | D: 275mm
– Weight 3,9 kg
Thermally
– Ambient temperature 0°C – 40°C
Electrically
– electrical protection class Safety Extra Low Voltage, SELV
– Operating voltage 5V DC via USB-C
Power connector input
USB-C
